T1 Multi-Touch Ring Encoder (MTRE)

T1 Multi-Touch Ring Encoder (MTRE)

Gesture recognition has become commonplace in a wide range of electronics including mobile phones and tablets. Its ease of use could be described as instinctual. Grayhill's Multi-Touch Ring Encoder with Instinct™ will aid in the design of uncluttered, easy-to-clean instrumentation for the following applications: Ultrasound equipment, medical imaging controllers, patient monitors, surgery equipment and molecular imaging.

A Shorter Distance from Mind to Machine

An intuitive, easy-to-use interface improves productivity. Instinctive movements provide a variety of commands, all without the fingers leaving the touchpad. This allows faster interaction without needing to take eyes off the screen. Plus, ergonomics are improved by consolidating all controls within easy reach.

Simplicity in use & Device Design

The Multi-Touch Ring Encoder can replace touchscreens, keypads, trackballs, switches, and joysticks. This makes for clean design and cuts costs of manufacturing. The MTRE increases the engineer's flexibility in building functionality into any product, while reducing front panel size and complexity.

Ring_Side_View

Features
• Grayhill Instinct™ Gesture Recognition
• Three devices in one:
   ◦ Multi-Touch Touchpad
   ◦ Optical Encoder
   ◦ Pushbutton
• Impervious to cleaning solutions
• Easy to integrate into any device
• Rugged, scratch-resistant surfaces
• Backlit illumination
• Colored highlight ring
• Redundant quadrature encoder output
• Redundant push button output
• USB compatible HID device

Possible applications include:
• Medical devices
• Industrial/Robotic controls
• Gaming machines

The Instinct™ Software Development Kit (SDK)
Grayhill offers a Software Development Kit (SDK) for OEM design engineers to use Instinct™ Touch Technology for their specific equipment design and application. The kit is available directly from Grayhill or from one of several distributers. For more detailed information, including a copy of the User's Guide, Contact Us.
